| Model | ABC-1300 | ABC-1600 | ABC-2100 |
| Suitable material | HDPE LDPE LLDPE | HDPE LDPE LLDPE | HDPE LDPE LLDPE |
| Film width | 800-1200mm | 1000-1500mm | 1200-2000mm |
| Flim thickness | 0.028-0.20mm | 0.028-0.20mm | 0.03-0.20mm |
| Max. Extrusion output | 150kg/hr | 200kg/hr | 250kg/hr |
| Screw diameter | Aφ50 Bφ55 Cφ50 | Aφ55 Bφ65 Cφ55 | Aφ65 Bφ75 Cφ65 |
| Screw l/d length | 32:1 | 32:1 | 32:1 |
| Main motor | A18.5kw+B22kw+C18.5kw | A22kw+B30kw+C22kw | A30kw+B37kw+C30kw |
| Die size | 300mm | 350mm | 500mm |
| Air blower | 7.5kw | 11kw | 15kw |
| Roller width | 1300mm | 1600mm | 2100mm |
| Take-up motor | 1.5kw | 2.2kw | 2.2kw |
| Winding motor | 1.5kw | 2.2kw | 2.2kw |
| Outline dimension(L×W×H) | 9.5×4.5×7.5m | 10.5×5.0×9m | 11.5×5.5×10m |
